Energy Storage System

X3 PCAB

X3 PCAB

750 kW

Versatile Applications

  • Supports connection to diesel generators to ensure stable energy supply

  • The energy storage side supports bus integration in the switching cabinet for versatile applications

  • Supports building on/off-grid, microgrid, and PV-energy storage-DG solutions

High Efficiency

  • Supports a maximum switching power of up to 750kW

  • Integrated EMS for intelligent monitoring and rapid response

  • Millisecond-level switching between grid-connected and off-grid modes


Safer and Reliable

  • Supports Type II surge protection

  • Supports water ingress alerts, over-temperature warnings, and door lock status feedback

  • Certified with IEC 61439-1, IEC 61439-2, IEC 61000, and IEC 60730 standards


Environmental Adaptability

  • IP55 protection rating, suitable for outdoor installation

  • Supports operation in environments ranging from -30°C to 55°C

  • Reliable operation at 3000 meters without derating


Why X3 PCAB

Experience the cutting-edge in power management with SolaX Power's X3 PCAB series. This top-tier product supports an impressive maximum switching power of up to 750kW, enabling swift millisecond-level transitions between grid-connected and off-grid modes. Equipped with an integrated EMS for intelligent monitoring and rapid response, it ensures your power needs are met with precision and reliability.

The X3 PCAB series is safeguarded with Type II surge protection and comes with multiple safety alerts including water ingress and over-temperature warnings, providing peace of mind. Certified to IEC standards, it boasts an IP55 protection rating, making it ideal for outdoor installations and capable of withstanding harsh environments ranging from -30°C to 55°C. It operates reliably even at 3000 meters without performance loss.

Designed for versatility, the X3 PCAB series supports a range of applications including on/off-grid, microgrid, and PV-energy storage systems. It allows for connection to diesel generators and bus integration in the switching cabinet for a stable energy supply. Optimized for high-power solar panels, this series offers a flexible and adaptable solution for all your power management needs.


Documents
Installation Manual
English
Language
English
Format
PDF
Size
35.5 MB
Last updated
04/03/2025
Language
English
Format
PDF
Size
35.5 MB
Last updated
04/03/2025
User Manual
Language
English
Format
PDF
Size
24.3MB
Last updated
04/03/2025
Datasheet
Language
English
Format
PDF
Size
9.95MB
Last updated
04/03/2025
