750W/ 800W / 900W / 1000W / 1200W
1300W/ 1500W / 1600W / 1800W / 2000W / 2200W
Support micro-grid solution
Support AC coupling solution
Support 1-phase microinverter integration into 3-phase power grids
Max. 1200VA output power
Max. 20A DC input current
Two MPPT channels, small size, light weight
Reactive power control
Rapid shutdown function
Easy to install and maintain
Built-in industrial grade Wi-Fi module
Safety protection relay integrated
IP67 protection class
The SolaX X1-Micro series is renowned for its exceptional power output, positioning itself as one of the top-rated models among 2-in-1 microinverters, boasting an impressive capacity of up to 1200 VA. Specifically designed to cater to the latest and previous generation of high-power modules, these microinverters feature two independent MPPTs and robust support for input current and output power.
Seamlessly incorporating Wi-Fi wireless technology, the X1-Micro series ensures reliable and consistent communication, offering users a smooth monitoring and control experience. Delivering a cost-effective solution, these microinverters are highly suitable for both residential and commercial solar applications. Furthermore, they are fully compatible with the SolaX Hybrid system and seamlessly integrate with various AC coupled systems available in the market, thus enhancing their versatility and adaptability.
| Max. PV input voltage | 60V |
| Max. PV input current | 2*15 |
| Start-up voltage | 22V |
| No. of MPP trackers/Strings per MPP tracker | 2/1 |
| Dimensions (W*H*D) | 260*212*40mm |
| Net weight | 4.1kg |
| Max. PV input voltage | 60V |
| Max. PV input current | 2*15 |
| Start-up voltage | 22V |
| No. of MPP trackers/Strings per MPP tracker | 2/1 |
| Dimensions (W*H*D) | 260*212*40mm |
| Net weight | 4.1kg |
| Max. PV input voltage | 60V |
| Max. PV input current | 2*16 |
| Start-up voltage | 22V |
| No. of MPP trackers/Strings per MPP tracker | 2/1 |
| Dimensions (W*H*D) | 260*212*40mm |
| Net weight | 4.1kg |
| Max. PV input voltage | 60V |
| Max. PV input current | 2*20 |
| Start-up voltage | 22V |
| No. of MPP trackers/Strings per MPP tracker | 2/1 |
| Dimensions (W*H*D) | 260*212*40mm |
| Net weight | 4.1kg |
High Power Output. The X1-Micro 4in1 series microinverters deliver an impressive output power of up to 2200VA, suitable for high-power PV modules.
Multiple MPPT Channels. Equipped with 4 independent MPPT channels, supporting up to 20A DC input current, ensuring compatibility with the latest and previous generation high-power PV modules, allowing substantial input current and output power capabilities.
Built-in industrial-grade Wi-Fi module for high reliability.
Monitoring and Control. Integrated with the SolaX Cloud, enabling easy monitoring and control through web and mobile apps.
Safety Features. Includes a safety protection relay, Reactive Power Control, and Rapid Shutdown Function, ensuring safe operation.
System Compatibility. Supports micro-grid and AC coupling solutions with existing storage systems. Compatible with SolaX Hybrid systems and supports the integration of a single-phase microinverter into a three-phase power grid system.
Compact and Lightweight. Designed for easy installation and maintenance with a small size and lightweight structure.
High Protection Rating. IP67 protection class ensures durability and reliability in various environmental conditions.
The SolaX X1-Micro series of microinverters stands out as one of the most powerful options in the 4-in-1 microinverter category, boasting an impressive output power of up to 2200 VA. These cutting-edge products are specifically designed to handle the latest and previous generation of high power modules with 4 independent MPPTs, allowing for substantial input current and output power capabilities. The integration of a reliable WiFi wireless solution ensures consistent and dependable communication functionality. Offering a cost-effective solution for both residential and commercial solar applications, these microinverters are fully compatible with SolaX Hybrid systems and can also be seamlessly integrated into AC coupled systems on the market.
| Parameters | X1-Micro 1300 |
| Max. PV input power [W] | 300 to 505+ |
| Max. PV input voltage [V] | 60 |
| MPPT voltage range [V] | 22-60 |
| Start-up voltage [V] | 20 |
| Max. PV input current [A] | 4 × 12 |
| Max. input short circuit current Isc [A] | 4 × 20 |
| No. of MPP trackers | 4 |
| Strings per MPP tracker | 1 |
| Rated AC output power [VA] | 1300 |
| Maximum continuous output power [VA] | 1300 |
| Maximum continuous output current [A] | 5.91@220V, 5.66@230V, 5.42@240V |
| Rated grid voltage/range [V] | 220 or 230 or 240 / 180-275 |
| Nominal AC frequency/range [Hz] | 50/45–55 or 60/55–65 |
| Maximum units per 10AWG branch | 6@220V, 7@230V, 7@240V |
| Maximum units per 12AWG branch | 5@220V, 5@230V, 5@240V |
| Power Factor range | >0.99(-0.8~0.8 adjustable) |
| THDi (Rated power) [%] | <3 |
| Parameters | X1-Micro 1500 |
| Max. PV input power [W] | 320 to 540+ |
| Max. PV input voltage [V] | 60 |
| MPPT voltage range [V] | 22-60 |
| Start-up voltage [V] | 20 |
| Max. PV input current [A] | 4 × 13 |
| Max. input short circuit current Isc [A] | 4 × 20 |
| No. of MPP trackers | 4 |
| Strings per MPP tracker | 1 |
| Rated AC output power [VA] | 1500 |
| Maximum continuous output power [VA] | 1500 |
| Maximum continuous output current [A] | 6.82@220V 6.53@230V 6.25@240V |
| Rated grid voltage/range [V] | 220 or 230 or 240 / 180-275 |
| Nominal AC frequency/range [Hz] | 50/45–55 or 60/55–65 |
| Maximum units per 10AWG branch | 5@220V, 6@230V, 6@240V |
| Maximum units per 12AWG branch | 4@220V, 4@230V, 5@240V |
| Power Factor range | >0.99(-0.8~0.8 adjustable) |
| THDi (Rated power) [%] | <3 |
| Parameters | X1-Micro 1600 |
| Max. PV input power [W] | 360 to 600+ |
| Max. PV input voltage [V] | 60 |
| MPPT voltage range [V] | 22-60 |
| Start-up voltage [V] | 20 |
| Max. PV input current [A] | 4 × 15 |
| Max. input short circuit current Isc [A] | 4 × 20 |
| No. of MPP trackers | 4 |
| Strings per MPP tracker | 1 |
| Rated AC output power [VA] | 1600 |
| Maximum continuous output power [VA] | 1600 |
| Maximum continuous output current [A] | 7.28@220V 6.96@230V 6.67@240V |
| Rated grid voltage/range [V] | 220 or 230 or 240 / 180-275 |
| Nominal AC frequency/range [Hz] | 50/45–55 or 60/55–65 |
| Maximum units per 10AWG branch | 4@220V, 5@230V, 5@240V |
| Maximum units per 12AWG branch | 4@220V, 4@230V, 4@240V |
| Power Factor range | >0.99(-0.8~0.8 adjustable) |
| THDi (Rated power) [%] | <3 |
| Parameters | X1-Micro 1800 |
| Max. PV input power [W] | 400 to 600+ |
| Max. PV input voltage [V] | 60 |
| MPPT voltage range [V] | 22-60 |
| Start-up voltage [V] | 20 |
| Max. PV input current [A] | 4 × 16 |
| Max. input short circuit current Isc [A] | 4 × 20 |
| No. of MPP trackers | 4 |
| Strings per MPP tracker | 1 |
| Rated AC output power [VA] | 1800 |
| Maximum continuous output power [VA] | 1800 |
| Maximum continuous output current [A] | 8.19@220V 7.83@230V 7.50@240V |
| Rated grid voltage/range [V] | 220 or 230 or 240 / 180-275 |
| Nominal AC frequency/range [Hz] | 50/45–55 or 60/55–65 |
| Maximum units per 10AWG branch | 4@220V, 5@230V, 5@240V |
| Maximum units per 12AWG branch | 3@220V, 4@230V, 4@240V |
| Power Factor range | >0.99(-0.8~0.8 adjustable) |
| THDi (Rated power) [%] | <3 |
| Parameters | X1-Micro 2000 |
| Max. PV input power [W] | 400 to 670+ |
| Max. PV input voltage [V] | 60 |
| MPPT voltage range [V] | 22-60 |
| Start-up voltage [V] | 20 |
| Max. PV input current [A] | 4 × 18 |
| Max. input short circuit current Isc [A] | 4 × 20 |
| No. of MPP trackers | 4 |
| Strings per MPP tracker | 1 |
| Rated AC output power [VA] | 2000 |
| Maximum continuous output power [VA] | 2000 |
| Maximum continuous output current [A] | 9.10@220V 8.70@230V 8.34@240V |
| Rated grid voltage/range [V] | 220 or 230 or 240 / 180-275 |
| Nominal AC frequency/range [Hz] | 50/45–55 or 60/55–65 |
| Maximum units per 10AWG branch | 4@220V, 4@230V, 4@240V |
| Maximum units per 12AWG branch | 3@220V, 3@230V, 3@240V |
| Power Factor range | >0.99(-0.8~0.8 adjustable) |
| THDi (Rated power) [%] | <3 |
| Parameters | X1-Micro 2200 |
| Max. PV input power [W] | 400 to 670+ |
| Max. PV input voltage [V] | 60 |
| MPPT voltage range [V] | 22-60 |
| Start-up voltage [V] | 20 |
| Max. PV input current [A] | 4 × 19.5 |
| Max. input short circuit current Isc [A] | 4 × 20 |
| No. of MPP trackers | 4 |
| Strings per MPP tracker | 1 |
| Rated AC output power [VA] | 2200 |
| Maximum continuous output power [VA] | 2200 |
| Maximum continuous output current [A] | 10.00@220V 9.57@230V 9.17@240V |
| Rated grid voltage/range [V] | 220 or 230 or 240 / 180-275 |
| Nominal AC frequency/range [Hz] | 50/45–55 or 60/55–65 |
| Maximum units per 10AWG branch | 4@220V, 4@230V, 4@240V |
| Maximum units per 12AWG branch | 3@220V, 3@230V, 3@240V |
| Power Factor range | >0.99(-0.8~0.8 adjustable) |
| THDi (Rated power) [%] | <3 |
